windows

YOW 225 TU THERMALLY BROKEN OPERABLE WINDOW FOR INSULATING GLASS

Article Image

YOW 225 TU windows have been designed and engineered to provide the highest level of quality. The windows have an overall depth of 2-1/4" and are thermally broken by means of ThermaBond Plus® technology developed by YKK AP.

YOW 225 TU windows may be installed as independent units or adapted to fit into most YKK AP storefront, window wall, or curtain wall systems. The vents are flush with the frame thus eliminating unsightly overlap. YOW 225 TU windows are available in a variety of configurations to accommodate project requirements.

YOW 225 TU windows may be installed as independent units or adapted to fit into most YKK AP storefront, window wall, or curtain wall systems. The vents are flush with the frame thus eliminating unsightly overlap. YOW 225 TU windows are available in a variety of configurations to accommodate project requirements.

FEATURES

Thermally Broken / Expedited Shipping

BENEFITS
Available configurations: Casement Outswing/Inswing, Project Out/In, & Fixed
AAMA/WDMA/I.S.2-97
AW-65 Operable
AW-100 Fixed
2-1/4″ frame depth
ThermaBond Plus® thermal break
Accepts 1″ glazing
Factory glazing & screens
Head/jamb receptors & stacking mullions
Standard heavy-duty hardware

DATA
Construction Use: New / Retrofit
Window Configurations: Casement Inswing / Casement Outswing / Fixed / Operable - Project In / Operable - Project Out
Frame Depth: 2-1/4"
Glass Type: Insulating
Thermal Method: Pour and Debridge

PRODUCT LINE
Anodized Plus® / Thermabond Plus®


YSW 400 T THERMALLY BROKEN SLIDING WINDOW FOR MONOLITHIC & INSULATING GLASS

Article Image

YOW 225 TU windows have been designed and engineered to provide the highest level of quality. The windows have an overall depth of 2-1/4" and are thermally broken by means of ThermaBond Plus® technology developed by YKK AP.

YOW 225 TU windows may be installed as independent units or adapted to fit into most YKK AP storefront, window wall, or curtain wall systems. The vents are flush with the frame thus eliminating unsightly overlap. YOW 225 TU windows are available in a variety of configurations to accommodate project requirements.

FEATURES
Thermally Broken / Expedited Shipping

BENEFITS
Available configurations: Casement Outswing/Inswing, Project Out/In, & Fixed
AAMA/WDMA/I.S.2-97
AW-65 Operable
AW-100 Fixed
2-1/4″ frame depth
ThermaBond Plus® thermal break
Accepts 1″ glazing
Factory glazing & screens
Head/jamb receptors & stacking mullions
Standard heavy-duty hardware

DATA
Construction Use: New / Retrofit
Window Configurations: Casement Inswing / Casement Outswing / Fixed / Operable - Project In / Operable - Project Out
Frame Depth: 2-1/4"
Glass Type: Insulating
Thermal Method: Pour and Debridge

PRODUCT LINE
Anodized Plus® / Thermabond Plus®


YES SSG TUH VENT THERMALLY BROKEN VENT WINDOW FOR STOREFRONT AND CURTAIN WALL

Article Image

Whether your goal is to maintain the architectural integrity of a historic building or to take advantage of the value derived from façade construction, impact resistant zero sightline vent windows are the ideal solution for your project.

The YES SSG TUH Vent delivers a standard product offering with sizes up to 36” X 60” (60” X 36”). This thermally broken, impact vent is compatible with YKK AP’s YHS 50 Storefront and YHC 300 Curtain wall systems.

FEATURES
Thermally Broken / Hurricane Mitigation

BENEFITS
Flexible Design – Blend seamlessly with the surrounding framing system to become virtually invisible when viewed from a distance. Insulating Glass units can be ordered with internal muntins.
Florida Product Approval – HVHZ

Operable ±65 PSF with White Bronze Cam Locks, ±80 PSF with Multi-Point Locks(VMPL)
Small Missile with .060 PVB/Large Missile with .090 PVB

Outstanding Thermal Performance: Meets the 2012 International Energy Conservation Code (IECC) through Zone 6 utilizing standard 1” Low E insulating glass. (U = 0.29 cog)

Designed for the Elements: Corrosive resistant accessories ensure a long operational life span of the unit.

DATA
Construction Use: New / Retrofit
Window Configurations: Casement Outswing / Operable - Project Out
Glass Type: Insulating
Thermal Method: Pour and Debridge

PRODUCT LINE
Anodized Plus® / ProTek® / Thermabond Plus®
