CURTAIN WALLS

YCW 750 OG OUTSIDE GLAZED OPEN BACK CURTAIN WALL SYSTEM

Article Image

YCW 750 OG (Outside Glazed) is a pressure wall system that provides the flexibility required for today’s projects.The system offers a wide variety of face covers and several different depth back members that can accommodate taller spans and higher design pressures. The system provides improved thermal performance to conserve energy and lower operating costs.

PRODUCT DATA FEATURES
Thermally Broken / Expedited Shipping

BENEFITS
• Design freedom
◦ Splayed mullions to create dramatic building aesthetics
◦ Variety of face covers
◦ Dual finish option (interior – exterior)
◦ Engineered to meet the most stringent building codes
• Stick built using concealed fasteners
• Low profile door sub-frames for YKK AP entrances

DATA
Construction Use: New / Retrofit
Sightline: 2-1/2"
Mullion Depth: 5-1/4", 6", 6-3/4" 7-1/2"
Framing Installation Method: Shear Block
Glazing Installation: Outside
Glass Type: Monolithic / Insulating
Glass Configuration: Front

PRODUCT LINE
Anodized Plus®


YCW 750 XT HIGH PERFORMANCE CURTAIN WALL FEATURING DUAL THERMAL BARRIERS

Article Image

YCW 750 XT yields best-in-class thermal performance and exceeds not only current codes, but also exceeds the most stringent green building codes and standards in the market today.

This 2-1/2″ sightline outside glazed curtain wall system utilizes MegaTherm® technology with structural polyamide struts (in 3 widths) that accommodate standard 1″ glazing units as well as advanced glazing options such as triple glazing and suspended film technology.To ensure long-term structural integrity, the dead load of the insulating glass rests on integrated structural supports, diverting this load away from the thermal barriers.

FEATURES
Advanced Thermal / Thermally Broken

BENEFITS
Outstanding Thermal Performance – three MegaTherm strut widths allow Glazing infills of 1″, 1-1/2″, and 2″ and overall U-factors as low as 0.17
Warmer interior surfaces – Increased resistance to condensation, with a CRFf up to 82
Optional integral sill flashing
Ability to integrate with building’s air-vapor barrier

DATA
Construction Use: New / Retrofit
Sightline: 2-1/2"
Mullion Depth: 1" Glazing Infill: 6", 7-1/2" │ 1-1/2" Glazing Infill: 8", 9" │ 1-3/4" Glazing Infill: 6-3/4", 8-1/4", 9-3/4" │ 2" Glazing Infill: 8-1/2", 10"
Framing Installation Method: Shear Block
Glazing Installation: Outside
Glass Type: Monolithic / Insulating
Glass Configuration: Front
Thermal Method: Iso Struts

PRODUCT LINE
Anodized Plus® / enerGfacade® / MegaTherm®

YCW 750 SSG TWO AND FOUR-SIDE SILICONE GLAZED CURTAIN WALL SYSTEM

Article Image

The popular YCW 750 family of products has been expanded to include 4-side structural silicone glazing. This stick built system is designed for glazing either in the field or in a climate controlled environment for increased quality assurance of critical seals.

Shop glazed cassettes interlock with integral adapters on horizontals to create full width engagement top and bottom.

FEATURES
Non Thermal

BENEFITS
Versatile Framing Design
4-side structural silicone shop glazing
2-side or 4-side structural silicone glazed in the field
4-Side captured (YCW 750 OG & YCW 750 IG)
90° inside and outside corners
Accommodates splayed wall designs
Structural setting block chairs
Variety of face covers
Dual Finish capability (inside / outside finish)

DATA
Construction Use: New / Retrofit
Sightline: 2-1/2"
Mullion Depth: 5" to 10-3/8" system depths available
Framing Installation Method: Shear Block
Glazing Installation: Outside / Structural
Glass Type: Monolithic / Insulating
Glass Configuration: Center

PRODUCT LINE
Anodized Plus®
